Hello, I made this project for fun.

The canonical repository is GitHub; GitLab is maintained only as a source mirror.

The server is TypeScript on Node/Bun. The client is Go. Operators talk to the server through a web panel or the Electron desktop app, and agents connect over encrypted WebSockets.

On Linux, Docker is the easiest way to run it. On Windows, a native bare-metal installation is strongly recommended instead of Docker Desktop.

Important

Use Overlord only on systems you own or are explicitly authorized to administer. Review the Acceptable Use Policy before deployment. Report vulnerabilities privately according to the Security Policy.

---

• Platform Recommendation
• Docker Quick Start (Recommended on Linux)
  • Windows (not recommended)
  • Linux
  • macOS
• Native Bare-Metal Installation
• Rust Lite Agent
• Production Package Scripts
• WebRTC Streaming
• OIDC / SSO Login
• Login Branding
• Docker Notes (TLS, reverse proxy, cache)

---

Platform Recommendation

Warning

Do not use Docker Desktop for a normal Windows deployment. Linux containers on Windows run through a WSL2/Hyper-V virtual machine. This is substantially slower than running Overlord directly on Windows or on a Linux host, and the extra virtualization/networking layer provides fewer host-integration features.

For the best experience, choose one of these:

1. Linux host: run the provided Docker Compose deployment (recommended), or use the native Linux scripts.
2. Windows host: run Overlord directly on Windows using the native/bare-metal scripts.

The Windows Docker Compose file remains available for compatibility and testing, but it is not the recommended Windows installation method.

---

Docker Quick Start (Recommended on Linux)

Docker is recommended on a Linux host. The macOS and Windows instructions are provided for compatibility and local testing; Windows users should prefer a native installation or move the server to Linux.

Windows and macOS use docker-compose.windows.yml. Linux uses the default docker-compose.yml (host networking).

After the first start, open https://localhost:5173. The default username is admin. Unless you set OVERLORD_PASS, first startup generates a one-time password in data/save.json (inside the container: /app/data/save.json). For Docker Compose, retrieve it with:

docker compose exec overlord-server grep bootstrapPassword /app/data/save.json

The first login requires a password change, after which the plaintext bootstrap password is removed from save.json. Existing installations are not reset; if an older installation still uses admin / admin, change it manually. Keep save.json private and back it up.

Agents authenticate only through the X-Agent-Token header. Rebuild any legacy agent that still places its token in the connection URL; query-string agent credentials are rejected.

---

Windows (not recommended)

Caution

Docker Desktop on Windows is virtualized, noticeably slower, and exposes fewer Overlord features than a native Windows or Linux installation. Prefer Windows bare metal, or deploy the server on Linux using the Linux Docker instructions.

Compatibility/testing only: Windows Docker Desktop

1. Install Docker Desktop

Either from the website:

• https://docs.docker.com/desktop/setup/install/windows-install/

Or with winget:

winget install -e --id Docker.DockerDesktop

Start Docker Desktop once, then verify:

docker --version
docker compose version

2. Get the project

git clone https://github.com/doesntbreaktos/Overlord.git
cd Overlord

3. Start it

docker compose -f docker-compose.windows.yml up -d

4. Get the initial password

The default username is admin. Retrieve the generated one-time password with:

docker compose -f docker-compose.windows.yml exec overlord-server grep bootstrapPassword /app/data/save.json

Use the value shown after bootstrapPassword. It is removed from save.json after you sign in and change it.

5. Open the panel

https://localhost:5173

6. Update later

docker compose -f docker-compose.windows.yml down
docker compose -f docker-compose.windows.yml pull
docker compose -f docker-compose.windows.yml up -d

7. Stop

docker compose -f docker-compose.windows.yml down

---

Linux

Step-by-step: Linux (Debian / Ubuntu / Kali)

1. Install Docker

Official docs: https://docs.docker.com/engine/install/debian/

Set up Docker's apt repository:

# Add Docker's official GPG key:
sudo apt update
sudo apt install ca-certificates curl
sudo install -m 0755 -d /etc/apt/keyrings
sudo curl -fsSL https://download.docker.com/linux/debian/gpg -o /etc/apt/keyrings/docker.asc
sudo chmod a+r /etc/apt/keyrings/docker.asc

# Add the repository to Apt sources:
sudo tee /etc/apt/sources.list.d/docker.sources <<EOF
Types: deb
URIs: https://download.docker.com/linux/debian
Suites: $(. /etc/os-release && echo "$VERSION_CODENAME")
Components: stable
Architectures: $(dpkg --print-architecture)
Signed-By: /etc/apt/keyrings/docker.asc
EOF

sudo apt update

On a derivative distro (e.g. Kali), replace the codename expansion with the matching Debian codename, e.g. bookworm.

Install Docker:

sudo apt install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin

Make sure the daemon is running:

sudo systemctl status docker

2. Grab the compose file

Make a folder for it, drop in the file, and you're done:

mkdir overlord && cd overlord
wget https://raw.githubusercontent.com/doesntbreaktos/Overlord/main/docker-compose.yml

No wget? Use curl:

mkdir overlord && cd overlord
curl -O https://raw.githubusercontent.com/doesntbreaktos/Overlord/main/docker-compose.yml

3. Start it

docker compose up -d

The Compose file itself is downloaded from the canonical GitHub repository, and the default image is pulled from GitHub Container Registry at ghcr.io/doesntbreaktos/overlord:latest.

Maintainers can publish a matching multi-architecture GHCR image from the overlord-ci workflow. Select Run workflow and enter the version currently declared by the server and agent (for example, 3.1.0). The workflow publishes version, major/minor, major, and latest tags to ghcr.io/doesntbreaktos/overlord. Keep the package visibility public so Compose can pull it without GitHub authentication.

4. Get the initial password

The default username is admin. Retrieve the generated one-time password with:

docker compose exec overlord-server grep bootstrapPassword /app/data/save.json

Use the value shown after bootstrapPassword. It is removed from save.json after you sign in and change it.

5. Open the panel

https://localhost:5173

or

https://IP:5173

6. Update later

From the same folder:

docker compose down
docker compose pull
docker compose up -d

7. Stop

docker compose down

---

macOS

Step-by-step: macOS

1. Install Docker Desktop

Either from the website:

• https://docs.docker.com/desktop/setup/install/mac-install/

Or with Homebrew:

brew install --cask docker

Start Docker Desktop once, then verify:

docker --version
docker compose version

2. Get the project

git clone https://github.com/doesntbreaktos/Overlord.git
cd Overlord

3. Start it

macOS uses the same compose file as Windows:

docker compose -f docker-compose.windows.yml up -d

4. Get the initial password

The default username is admin. Retrieve the generated one-time password with:

docker compose -f docker-compose.windows.yml exec overlord-server grep bootstrapPassword /app/data/save.json

Use the value shown after bootstrapPassword. It is removed from save.json after you sign in and change it.

5. Open the panel

https://localhost:5173

6. Update later

docker compose -f docker-compose.windows.yml down
docker compose -f docker-compose.windows.yml pull
docker compose -f docker-compose.windows.yml up -d

7. Stop

docker compose -f docker-compose.windows.yml down

---

Native Bare-Metal Installation

Use the included scripts to run without Docker. This is the recommended installation method on Windows.

Prerequisites:

• Bun in PATH
• Go 1.21+ in PATH

Windows (recommended)

Tip

This native Windows path avoids Docker Desktop's Linux VM and provides the best Windows performance and feature availability.

Development mode (starts server + client):

scripts\start-dev.bat

Production mode (build + run server executable):

scripts\start-prod.bat

After the server starts for the first time, open another PowerShell window and retrieve the generated password with:

(Get-Content "$env:APPDATA\Overlord\save.json" | ConvertFrom-Json).auth.bootstrapPassword

Sign in as admin. The first login requires a password change, after which the bootstrap password is removed from the file.

Build client binaries (adds client builds to the build queue):

scripts\build-clients.bat

Linux / macOS

Make scripts executable once:

chmod +x scripts/*.sh scripts/*.command

Development mode (server in background, client in foreground):

./scripts/start-dev.sh

Only server, or only client:

./scripts/start-dev.sh server
./scripts/start-dev.sh client

Production mode:

./scripts/start-prod.sh

After the server starts for the first time, open another terminal in the repository root and retrieve the generated password with:

grep bootstrapPassword Overlord-Server/data/save.json

Sign in as admin using the displayed value. The first login requires a password change, after which the bootstrap password is removed from the file.

---

Rust Lite Agent

Overlord-Lite is an experimental Rust client focused on authenticated connections, TLS identity pinning, and heartbeat/reconnect behavior. It supports interactive TTY console sessions while omitting plugins plus the full Go agent's desktop, webcam, audio, persistence, and OS-integration features. See Overlord-Lite/README.md for build instructions, configuration, and Build-page integration.

Production Package Scripts

Build a production-ready package where the server can still build client binaries at runtime.

Windows:

scripts\build-prod-package.bat

Output: release/

Linux / macOS:

./scripts/build-prod-package.sh

Output: release/prod-package/

Docker images and both package scripts fingerprint first-party JavaScript and CSS filenames with a deterministic build digest, then rewrite HTML and module imports to match. Development keeps readable stable paths. This provides safe immutable caching and removes version-stable asset URLs, but it is defense in depth rather than a substitute for putting the panel behind a VPN, firewall, or authenticated reverse proxy.

---

WebRTC Streaming

The remote desktop viewer has a Transport dropdown with three modes:

• Canvas (default): H.264 / JPEG / block frames over the existing WebSocket, decoded into a <canvas>. Highest latency, works anywhere the WS does.
• WebRTC P2P: browser ↔ agent direct when possible, with the bundled Coturn server as a fallback for restrictive or symmetric NAT. MediaMTX is not involved. Lowest latency on a direct route.
• WebRTC Relayed: agent publishes to a MediaMTX sidecar via WHIP, browser plays via WHEP. The server proxies signaling so the existing JWT auth + per-client RBAC still apply. Lowest-effort fallback when P2P can't punch through.

Building agents with WebRTC

WebRTC is opt-in per agent build. In the builder UI, tick the WebRTC checkbox before clicking Build. Without it, the Pion stack (~6 MB of Go modules) is not compiled in — any WebRTC start attempt from the operator returns webrtc support not compiled in and the viewer falls back to Canvas. The Canvas path always works regardless of the build setting.

The build tag (overlord_webrtc) is also available if you build agents outside the UI:

go build -tags overlord_webrtc ./cmd/agent

Coturn STUN / TURN

Compose starts overlord-coturn for ICE traversal in both P2P and MediaMTX Relayed modes. A one-time init service generates a random master secret and a neutral random TURN realm in the private overlord-turn-secret Docker volume. Overlord uses that secret to issue one-hour Coturn REST credentials independently to the authenticated P2P viewer and agent. MediaMTX reads the secret inside Docker and also generates expiring credentials for its WHIP/WHEP clients. No Google STUN server is used, and the master secret is never sent directly to a peer. Set OVERLORD_TURN_REALM only when you need an explicit realm; avoid product-identifying values because TURN authentication challenges disclose it.

The defaults work for same-machine testing. For LAN or internet access, set the address that both the browser and agent can reach in a .env file next to the compose file:

OVERLORD_TURN_HOST=turn.example.com
OVERLORD_TURN_EXTERNAL_IP=203.0.113.10

OVERLORD_TURN_HOST is placed in the ICE URLs and may be a public DNS name or IP. OVERLORD_TURN_EXTERNAL_IP tells Coturn which public address to advertise when the Docker host is behind NAT; omit it when Coturn binds the public interface directly. Do not use the Docker service name because peers outside the Compose network cannot resolve or reach it.

Allow and forward these inbound ports to the Coturn host:

• 3478/udp and 3478/tcp for STUN and TURN client connections.
• 49160-49200/udp for TURN relay allocations with the Linux Compose file.
• 40000-40040/udp with docker-compose.windows.yml, avoiding Windows' commonly excluded dynamic UDP range. Override it with OVERLORD_TURN_MIN_PORT and OVERLORD_TURN_MAX_PORT if necessary.

The bundled setup supports ordinary TURN over UDP and TCP. It intentionally does not enable turns: until a trusted Coturn TLS certificate and public hostname are configured.

MediaMTX sidecar

Compose starts an overlord-mediamtx service for Relayed mode. It needs:

• Port 8189/udp and 8189/tcp reachable from operators (WebRTC ICE traffic). The Windows / macOS compose publishes these; Linux uses host networking and shares the host's interfaces directly.
• No auth config — the Overlord server proxies every WHIP/WHEP request through /api/webrtc/... and enforces the existing operator JWT + RBAC there.

On Linux host networking, MediaMTX's HTTP signaling listener is explicitly bound to 127.0.0.1:8889; only the authenticated Overlord proxy can reach it. The ICE listeners remain externally reachable as required for media transport.

If you only ever want P2P, you can comment out the mediamtx: service in your compose file — only Relayed mode depends on it. MediaMTX is configured to use the same Coturn service as a client-only ICE fallback, but it is not itself a STUN/TURN server; Coturn handles all relay allocations.

LAN / public access

MediaMTX automatically discovers addresses assigned directly to its network interfaces. This covers ordinary Linux host-network and many LAN deployments, but it cannot reliably infer a public address created by NAT, port forwarding, a cloud load balancer, or a reverse proxy. It also cannot discover which public DNS name you intend operators to use.

Before using WebRTC Relayed from another machine, make sure MediaMTX advertises an address that both agents and operators can reach:

• Linux with host networking and no public NAT: normally nothing is required; MediaMTX sees the host's interfaces automatically.
• Public server behind NAT, port forwarding, or a cloud public-IP mapping: set the public IP or a DNS name that resolves to it.
• Windows / macOS Docker Desktop: set the host's reachable LAN/public address because automatic interface discovery sees the container network, not necessarily the Docker host.
• Same-machine testing on Docker Desktop: retain 127.0.0.1 in the list.

Set OVERLORD_WEBRTC_ADDITIONAL_HOSTS as a comma-separated list in the shell or in a .env file next to the compose file:

# LAN example
OVERLORD_WEBRTC_ADDITIONAL_HOSTS=192.168.1.42

# Public DNS plus LAN access
OVERLORD_WEBRTC_ADDITIONAL_HOSTS=stream.example.com,192.168.1.42

# Docker Desktop: same host plus other LAN machines
OVERLORD_WEBRTC_ADDITIONAL_HOSTS=127.0.0.1,192.168.1.42

Ensure inbound UDP 8189 is forwarded to the MediaMTX host/container; TCP 8189 is the slower fallback. Recreate the sidecar after changing the setting:

# Linux
docker compose up -d --force-recreate mediamtx

# Windows / macOS Docker Desktop
docker compose -f docker-compose.windows.yml up -d --force-recreate mediamtx

To verify the selected route, open chrome://webrtc-internals during a relayed stream and confirm that the chosen remote candidate points to the expected server address and preferably uses UDP.

Automatic public-IP discovery is possible with STUN, but it is not a complete replacement for this setting: it can require random UDP ports, does not discover your intended domain, and can fail behind restrictive or symmetric NAT. For predictable production deployments, explicitly setting the reachable IP/domain and forwarding fixed UDP port 8189 is recommended.

Remote desktop network impairment tests

On a Linux test host, scripts/rd-network-impairment.sh applies repeatable bandwidth, latency, jitter, and packet-loss profiles with tc netem. Give it the exact interface carrying the WebRTC traffic:

# Inspect interfaces first; do not guess the target.
ip link show

sudo bash scripts/rd-network-impairment.sh apply eth0 wan
bash scripts/rd-network-impairment.sh status eth0

# Always restore the interface after the test.
sudo bash scripts/rd-network-impairment.sh clear eth0

Available profiles are wan (20 Mbps), constrained (8 Mbps), and harsh (3 Mbps), with progressively higher delay, jitter, and loss. The rule affects all egress traffic on the selected interface, not only Overlord. The script refuses to touch loopback unless OVERLORD_NETEM_ALLOW_LOOPBACK=1 is explicitly set.

For each profile, start Remote Desktop with both Profile: Auto (best) and Bitrate: Auto, then watch the Stats HUD. Verify that bitrate falls before the profile steps down, decode/processing queues remain bounded, and the profile slowly recovers after clearing the impairment.

Advanced MediaMTX customization

The compose file passes a minimal set of MTX_* environment variables to MediaMTX — enough for Overlord to work. To change anything else (codecs, paths, ICE servers, etc.), either:

• Add more MTX_* variables to the mediamtx service's environment: block (every option in MediaMTX's docs is supported as an env var), or

• Provide a full mediamtx.yml via a bind mount:

  mediamtx:
    # ...existing config...
    volumes:
      - ./mediamtx.yml:/mediamtx.yml:ro


  Make sure the file exists on the host before the container starts — Docker will otherwise auto-create an empty directory at that path and fail with "not a directory".

---

OIDC / SSO Login

Overlord supports generic OIDC login for homelab identity providers such as Authentik, Authelia, Keycloak, Zitadel, and Dex. Local username/password login stays enabled as a fallback.

Configure your OIDC provider with this redirect URI:

https://YOUR_OVERLORD_HOST/api/oidc/callback

Then set the relevant environment variables:

OVERLORD_OIDC_ENABLED=true
OVERLORD_OIDC_LABEL=Sign in with SSO
OVERLORD_OIDC_ISSUER=https://auth.example.com/application/o/overlord/
OVERLORD_OIDC_CLIENT_ID=overlord
OVERLORD_OIDC_CLIENT_SECRET=change-me
OVERLORD_OIDC_REDIRECT_URI=https://overlord.example.com/api/oidc/callback
OVERLORD_OIDC_DEFAULT_ROLE=viewer
OVERLORD_OIDC_ALLOWED_DOMAINS=example.com
OVERLORD_OIDC_ADMIN_GROUPS=overlord-admins
OVERLORD_OIDC_OPERATOR_GROUPS=overlord-operators
OVERLORD_OIDC_VIEWER_GROUPS=overlord-viewers

New OIDC users are linked by the provider's issuer + sub identity. Email/username linking to an existing local account is disabled by default; enable OVERLORD_OIDC_ALLOW_EMAIL_LINK=true only if you trust your provider's verified email claims.

---

Login Branding

Self-hosted and enterprise deployments can brand the login screen with environment variables:

OVERLORD_LOGIN_BRAND_NAME=Acme SOC
OVERLORD_NAV_BRAND_NAME=Acme Console
OVERLORD_BRAND_ACCENT_COLOR=#14b8a6
OVERLORD_LOGIN_TITLE=Welcome to Acme Overlord
OVERLORD_LOGIN_SUBTITLE=Sign in with your Acme identity
OVERLORD_LOGIN_LOGO_URL=/assets/acme-logo.png
OVERLORD_LOGIN_LOGO_ALT=Acme logo
OVERLORD_NAV_LOGO_URL=/assets/acme-nav-logo.png
OVERLORD_NAV_LOGO_ALT=Acme logo
OVERLORD_LOGIN_HERO_IMAGE_URL=/assets/acme-login.jpg
OVERLORD_LOGIN_HERO_IMAGE_ALT=Acme operations center
OVERLORD_LOGIN_FOOTER_TEXT=Authorized Acme access only
OVERLORD_LOGIN_SUPPORT_TEXT=Need access help?
OVERLORD_LOGIN_SUPPORT_URL=https://help.example.com
OVERLORD_LOGIN_ICON_CLASS=fa-solid fa-shield-halved

Logo, hero, and support URLs accept absolute http(s) URLs or root-relative paths. If no logo URL is set, the UI uses OVERLORD_LOGIN_ICON_CLASS. The same options can also be managed from Settings → Branding.

---

Docker Notes (TLS, reverse proxy, cache)

Notes on configs and workarounds.

BuildKit cache for faster rebuilds

docker-compose.yml ships with build.cache_from and build.cache_to pointing at .docker-cache/buildx. Local builds reuse it automatically — no extra setup.

Runtime client build cache

The compose setup uses a persistent volume for runtime client builds:

• Volume: overlord-client-build-cache
• Mount: /app/client-build-cache
• Env: OVERLORD_CLIENT_BUILD_CACHE_DIR (default /app/client-build-cache)

The server runs as UID/GID 1000:1000 with all Linux capabilities dropped and a read-only root filesystem. A one-shot Compose service repairs ownership on volumes created by older root-running releases. The mutable Go agent source is copied into an ephemeral tmpfs at startup, while finished builds and compiler caches remain in persistent volumes. MediaMTX runs as 65534:65534 with the same read-only and capability restrictions.

Self-signed certificate identity

New self-signed certificates use independently randomized country, region, locality, organization, organizational unit, and common-name values. Endpoint validation still uses the configured hostname/IP SANs. On startup, the exact legacy O=Overlord self-signed profile is reissued with randomized metadata using its existing private key. This changes the certificate subject, thumbprint, and browser trust entry but preserves the SPKI pin embedded in agents. Reinstall the downloaded certificate in browsers/OS trust stores after the first upgraded restart. Set OVERLORD_TLS_MIGRATE_LEGACY_CERT=false only to postpone this migration.

macOS CGO builds on Linux/Docker

When a macOS target is selected with CGO enabled, the builder asks for a user-provided macOS SDK archive. Package the complete MacOSX*.sdk directory as .tar.xz, .tar.gz, .tgz, or .tar and upload it from the Build page. The archive must contain the SDK's System/Library/Frameworks and usr directories.

The upload is limited to 1 GB, belongs to the authenticated user, can be used for only one build, and is deleted after the build. Unused uploads expire after one hour. The Docker image supplies Clang and LLD; Apple SDK files are never bundled or downloaded by Overlord.

Certbot TLS

To use Let's Encrypt certificates in production Docker:

1. Set OVERLORD_TLS_CERTBOT_ENABLED=true
2. Set OVERLORD_TLS_CERTBOT_DOMAIN=your-domain.com
3. Mount letsencrypt into the container read-only, e.g. /etc/letsencrypt:/etc/letsencrypt:ro

Default cert paths:

cert: /etc/letsencrypt/live/<domain>/fullchain.pem
key:  /etc/letsencrypt/live/<domain>/privkey.pem
ca:   /etc/letsencrypt/live/<domain>/chain.pem

Override with:

• OVERLORD_TLS_CERTBOT_LIVE_PATH
• OVERLORD_TLS_CERTBOT_CERT_FILE
• OVERLORD_TLS_CERTBOT_KEY_FILE
• OVERLORD_TLS_CERTBOT_CA_FILE

Reverse proxy TLS offload

Overlord can serve HTTP only on loopback while nginx, Caddy, Traefik, IIS, or another trusted reverse proxy owns the public HTTPS certificate. Browsers and agents must still use the public https:// / wss:// address.

HTTP/3 is enabled automatically when Overlord terminates TLS itself. QUIC uses UDP on the same port as HTTPS (5173 by default), so direct deployments must allow both TCP and UDP on that port. HTTP/1.1 remains enabled for initial Alt-Svc discovery, health checks, clients without HTTP/3, and WebSocket upgrades. When OVERLORD_TLS_OFFLOAD=true, the reverse proxy owns public HTTP/3 support because Bun's internal listener has no TLS.

The unauthenticated /health endpoint accepts only loopback clients. To verify both advertisement and an actual QUIC transfer, run the check on the Overlord host with an HTTP/3-capable curl build:

.\scripts\test-http3.ps1 https://127.0.0.1:5173/health -AllowUntrustedCertificate

For a self-signed certificate, add -AllowUntrustedCertificate.

To compare cold HTTP/1.1 and HTTP/3 request timings:

.\scripts\benchmark-http3.ps1 https://127.0.0.1:5173/health -Requests 30 -AllowUntrustedCertificate

The benchmark selects an HTTP/3-capable curl automatically, validates the protocol used by every sample, prints average/p50/p95 timing, and saves the raw measurements as CSV.

For a native install or Linux Docker with host networking, add this to .env:

HOST=127.0.0.1
OVERLORD_TLS_OFFLOAD=true
OVERLORD_HEALTHCHECK_URL=http://127.0.0.1:5173/health

For Docker Desktop (docker-compose.windows.yml), the container must listen on all of its own interfaces while Docker publishes the port on host loopback:

HOST=0.0.0.0
OVERLORD_PUBLISH_HOST=127.0.0.1
OVERLORD_TLS_OFFLOAD=true
OVERLORD_HEALTHCHECK_URL=http://127.0.0.1:5173/health

Restart Overlord after changing .env. The reverse proxy upstream is then http://127.0.0.1:5173. It must preserve Host, set X-Forwarded-Proto: https and X-Forwarded-For, support WebSocket upgrades, and use timeouts/body limits suitable for long sessions and file uploads.

Ready-to-copy Caddy and nginx configurations are in deploy/reverse-proxy/. Those examples accept TLS 1.3 only. This is also the required deployment mode when strict TLS 1.3 rejection is needed: Bun's native Bun.serve TLS listener currently negotiates TLS 1.3 by preference but does not expose an effective per-server minimum-version setting.

When enabled:

• Overlord skips certificate generation and serves internal HTTP.
• Authentication cookies remain Secure because public TLS terminates at the proxy.
• Proxy source-IP headers are trusted for auditing, bans, and rate limiting.
• The internal HTTP listener must never be exposed directly to the internet.

Source IP behind a domain / reverse proxy

If the dashboard, audit log, or IP bans show all agents as 172.x.x.x (or some other proxy/bridge IP), something between the agent and Bun is rewriting the source IP. Two independent flags govern this:

• OVERLORD_TLS_OFFLOAD — TLS terminates at the proxy; Overlord runs plain HTTP internally.
• OVERLORD_TRUST_PROXY — honor X-Forwarded-For / X-Real-IP / CF-Connecting-IP so dashboard/audit/IP-bans see the real client. Auto-enabled when TLS_OFFLOAD=true.

Common shapes:

Setup	TLS_OFFLOAD	TRUST_PROXY
Domain, no proxy (Linux host networking; certbot inside Overlord; Cloudflare DNS-only)	false	false
Domain, proxy does TLS (Render, nginx terminating TLS → http upstream)	true	auto (true)
Domain, proxy in front but Overlord still does TLS (Cloudflare orange-cloud Full Strict; nginx with proxy_pass https://)	false	true

Only enable OVERLORD_TRUST_PROXY when a trusted reverse proxy is in front. If Overlord is directly exposed and you enable it, agents can spoof their source IP by sending their own X-Forwarded-For header, breaking IP bans and audit accuracy. The upstream proxy also has to be configured to inject the header (Cloudflare does by default; nginx/Caddy/Traefik need explicit directives).

If you're using docker-compose.windows.yml or docker-compose.quickstart.yml (Docker Desktop bridge networking) with no reverse proxy, Docker itself rewrites source IPs to the bridge gateway and there is no header to recover from — TRUST_PROXY cannot help. Either switch to Linux host networking or put a real reverse proxy in front.

Notes

• Keep HOST=0.0.0.0 inside the container. Limit exposure with OVERLORD_PUBLISH_HOST, not the bind host.
• If your .env secret/password contains $, escape it as $$ to avoid Docker Compose variable-expansion warnings.
